PRODUCT MANUAL
Overview
| Quick Details | |||||
| Storage: | Oil | Drive Wheel: | 6x4 | Horsepower: | 251 - 350hp |
| Transmission Type: | Manual |
|
Diesel |
|
15001 - 30000L |
| Engine Capacity: | 20000 |
|
10025*2500*3600 | Brand Name: | sinotruk |
| Place of Origin: | China (Mainland) | Model Number: | SINOTRUK HOWO 6X4 20.000 Liters Fuel Tank Truck(20CBM) |
|
25000 |
| Product name: | SINOTRUK HOWO Fire Truck- 12 CBM (LHD) | Transmission: | HW19710 |
|
7000kg*2 |
|
16000kg*2 | Type: | 12R22.5 | Spare tyre: | with one spare tyre |
| cargo body size: | 10025*2500*3600 | Color: | Buyer's Request | ||
Supply Ability
Supply Ability: 300 Unit/Units per Month
Packaging & Delivery
Packaging Details: naked packing,shipment by roro or bulk vessel
Port: Tianjin, Shanghai, Qingdao or as your needs
Packaging Details: naked packing,shipment by roro or bulk vessel
Port: Tianjin, Shanghai, Qingdao or as your needs
SINOTRUK HOWO 6X4 20.000 Liters Fuel Tank Truck(20CBM)
Specification
| abin | HOWO 76 Standard Cab With one bed and air condition, 70° hydraulically tillable to the front as attached photo for ref. | |||
| Vehicle Main Dimensions | (L x W x H)mm | 10900×2490×3650 | ||
| Wheel base (mm) | 5225+1350 | |||
| Approach/Departure angle(°) | 16/11 | |||
| Weight in KGS | Tare Weight | 12000 | ||
| Loading Capacity | 12870 | |||
| Front axles loading capacity | 7000 | |||
| Rear axles loading capacity | 2x16000 | |||
| Max. driving speed（km/h） | 90 | |||
| Engine | Brand | SINOTRUK | ||
| Model | WD615.69 | |||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |||
| Horse Power（HP) | 336 | |||
| Emission standard | Euro 2 | |||
| Gearbox | HW19710 , 10 forwards & 2 reverse | |||
| Clutch | Reinforced diaphragm clutch, diameter 430mm | |||
| Steering Gear | ZF 8098,power steering, hydraulic steering with power assistance | |||
| Fuel tank (L) | 400 | |||
| Tire | 12R22.5 tubeless tire, 11 pieces with one spare | |||
| Brakes |
Service brake: dual circuit compressed air brake Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
|||
